TerraMaster NAS Server

NAS-server TerraMaster F8 SSD Plus med 8 M.2 2280-platser, stöd för RAID 0/1/5/6/10 och JBOD, 16 GB DDR5 RAM och 10 Gigabit Ethernet med iSCSI-stöd.

Utformad för mångsidig nätverkslagring i hem- eller kontorsmiljöer, stöder denna TerraMaster NAS upp till 64 TB och drivs av en 8-kärnig Intel N-series N305-processor (upp till 3.8 GHz). Den stöder vanliga fil- och hanteringsprotokoll inklusive FTP, SMB, NFS, SSH och SNMP, och erbjuder fjärråtkomst via TNAS.online tillsammans med säkerhetskopiering, ögonblicksbilder och säkerhetsfunktioner såsom AES-hårdvarukryptering, brandväggsskydd och LDAP-stöd.

• M.2 2280 SSD-lagring med 8 platser (0 installerade / 8 max)
• Stöd för RAID 0/1/5/6/10, JBOD, RAID-migrering och RAID Hot Spare
• 10GbE RJ-45 plus 3 x USB 3.2 Gen 2 Type-A och HDMI-utgång
• Stöd för filsystemen Btrfs och EXT4 med ögonblicksbildsfunktion
• VPN-server och VPN-klient, webbserver och DLNA-stöd
• Stöder Windows, macOS, Linux, iOS 14 och Android 10 eller senare

Byggd för att hantera flera samtidiga anslutningar och flexibel delning hjälper TerraMaster F8 SSD Plus till att hålla data tillgängliga, skyddade och enkla att hantera.

Hybrid direktansluten lagringskapsling TerraMaster D8 Hybrid 2 kombinerar fyra SATA HDD/SSD-fack och fyra M.2 NVMe SSD-platser med upp till 152 TB råkapacitet och USB 3.2 Gen 2 Type-C-anslutning.

Utformad för videoredigering, fotograferingsarbetsflöden, mediebibliotek, säkerhetskopieringslagring och datahantering med hög kapacitet, låter den aktiva projekt använda NVMe SSD:er medan större hårddiskar hanterar långtidslagring.

• Upp till 1,020 MB/s sekventiell läshastighet med NVMe SSD-lagring
• Upp till 980 MB/s HDD RAID-läsprestanda, beroende på konfiguration
• Verktygsfria Push-Lock SATA-enhetsvaggor och förenklad M.2-installation
• TerraMaster Power Management för stabil och långvarig drift
• Kompatibel med Windows, macOS, Linux, NAS-system och vanliga filsystem

Med hybridlagring, plug-and-play-drift och flexibelt stöd för säkerhetskopiering hjälper D8 Hybrid 2 till att hålla snabb arbetsdata och stora arkiv i en och samma skrivbordskapsling.

The TerraMaster F2-425 is a 2-bay NAS server equipped with an Intel N5095 quad-core processor, 4 GB of DDR4 memory and a 2.5GbE network port. It supports 3.5" and 2.5" HDDs and SSDs with a total capacity of up to 60 TB. Running TOS 6, the F2-425 provides centralized storage, file synchronization, backups, remote access and AI-assisted photo management. Hardware decoding and transcoding support for 4K content makes it suitable for multimedia use, while RAID support provides flexible storage configurations. With three USB ports and an HDMI output, the server also offers convenient connectivity for external storage and displays.

The TerraMaster F4-425 Plus is a 4-bay NAS server designed for high-speed data storage, backup, synchronization, and private cloud applications. It features an Intel N95 quad-core processor with speeds of up to 3.4 GHz, 8 GB of DDR4 memory expandable to 32 GB, four SATA drive bays, three M.2 NVMe slots, and two 5GbE network ports. Hardware-accelerated 4K video processing, multiple RAID configurations, AES-NI encryption, and comprehensive backup functions provide a flexible platform for home users, professionals, and small businesses.

The TerraMaster F4-425 is a 4-bay NAS server for centralized data storage, backup, synchronization, and multimedia use. It features an Intel N5095 quad-core processor with speeds of up to 2.9 GHz, 4 GB of DDR4 memory expandable to 16 GB, and a 2.5GbE network port. Four bays support 3.5" and 2.5" SATA HDDs and SSDs with a total capacity of up to 120 TB. TOS 6 provides tools for file management, remote access, data protection, synchronization, and multimedia streaming, making the F4-425 suitable for home and small-office environments.

The TerraMaster F6-424 is a 6-bay NAS server built for demanding home and business environments. It combines an Intel N95 quad-core processor with 8 GB of DDR5 memory, dual 2.5GbE networking, and two M.2 NVMe slots for SSD caching. Six drive bays support HDDs and SSDs with up to 132 TB of total storage, while multiple RAID configurations provide flexible options for capacity, performance, and data protection. The TOS operating system adds comprehensive backup, synchronization, virtualization, multimedia, and security functions. Hardware-accelerated 4K video decoding and support for Docker, VirtualBox, iSCSI, and business applications further expand its capabilities.

The TerraMaster F8 SSD is an all-flash 8-bay NAS server designed for users who need fast and compact network storage. It combines an Intel N95 quad-core processor with 8 GB of DDR5 memory and eight M.2 NVMe 2280 slots supporting up to 64 TB of storage. A 10GbE network port enables transfer speeds of up to 1020 MB/s, while hardware-accelerated 4K video decoding supports demanding multimedia applications. Multiple RAID configurations provide flexible storage and data protection options. With three USB 3.2 ports, low noise levels, and a compact 0.6 kg chassis, the F8 SSD is suitable for home users, content creators, and small businesses.

The TerraMaster F2-425 Plus is a high-performance 2-bay NAS server designed for fast, flexible data storage in homes and small businesses. It combines an Intel N150 quad-core processor with 8 GB of DDR5 5600 MHz memory and two 5GbE network ports for rapid data transfers. Two SATA bays support HDDs and SSDs, while three M.2 NVMe PCIe 3.0 slots provide additional high-speed storage, with total capacity reaching up to 84 TB. Hardware-accelerated 4K video processing, private cloud functionality, advanced backup tools, and comprehensive security features make it a versatile central storage solution.

The TerraMaster F4 SSD is a compact 4-bay NAS server designed for fast, low-noise storage based entirely on M.2 NVMe SSDs. It combines an Intel N95 processor with 8 GB of DDR5 memory and a 5GbE network port for high-speed file transfers, backups, and remote access. Four M.2 NVMe slots provide flexible storage configuration, while hardware-accelerated 4K video processing supports demanding multimedia applications. Advanced backup, synchronization, RAID, cloud integration, and security features make the F4 SSD suitable for home users, media libraries, and small business environments.

The TerraMaster T12-500 Pro is a 12-bay NAS server designed for demanding business environments that require high storage capacity, fast networking, and comprehensive data protection. It combines a 10-core Intel Core i7-1255U processor with 16 GB of DDR5 memory, expandable to 64 GB, and supports up to 288 TB of raw storage using SATA HDDs and SSDs. Two 10GbE ports provide high-speed network connectivity, while two M.2 NVMe PCIe 4.0 slots can be used for SSD caching. With hardware encryption, advanced backup functions, hot-swap support, and extensive TOS features, the T12-500 Pro is suitable for centralized file storage, backups, and business applications.
