ABB Kwh meter#b24 111-100

Electric meter 3 phase for transformer measurement with pulse/alarm output B24 111-100 Steel Product description: Electric meter for transformer measurement. 3P+N, 230-400V MID approved Cl. B (class 1), outputs for pulse or alarm. Electric meters are for DIN rail mounting. The wires are connected at the top and bottom of the electric meters. LCD display showing kWh, instantaneous values in current, power per phase and total, voltage, frequency. Automatic installation control. The meter is available in several variants for both single-phase and three-phase installations, for active energy in one direction (import) or two-way (import and export), MID approved as a billing meter according to: IEC 62052-11, IEC 62053-21 , EN 50470-1, EN 50470-3 Technical specifications: Mounting method: DRA (DIN rail adapter) Type: Measuring transformer Suitable for: Reference Display type: Digital
