Varunummer: 2764824
Hager Rcbo 1p+n 6ka b-10a 30ma a
RCBO 1P+N 6kA B-10A 30mA ATechnical data:Release curve: BPoles: 2 poles.Nominal load (in): 10 ARated Voltage (Un): 230V + 10% / -15%Rated output current (Idn): 30mASensitivity Class AFrequency: 50HzRated breakdown: 6kA in h.t. EN61009-1IP protection: IP2x mounted in enclosure.Temperature: 30 ° C in h.t. EN61009-Pollution rate: 2 in h.t. EN61009-1
1 300,00 kr
1 040,00 kr exkl. moms
Gratis frakt
Leverantör, 2-3 vardagar leveranstid
HPFI / circuit breaker combo 1P+N 10AProduct description: HPFI ADA910G / circuit breaker combo. 1P+N 10A. The combo-circuit breaker is a compact unit that ensures protection against overload, short circuit, and ground fault. It protects people and animals from electric shock in residential and commercial buildings. It also protects property from fire in case of insulation failure.Technical data:Trip curve: BPoles: 2 poles.The neutral is located on the right side.Rated current (In): 10 ARated voltage (Un): 230V +10%/-15%Nominal tripping current (Idn): 30mASensitivity Class AFrequency:50Hz Nominal breaking capacity:6kA according to EN61009-1 IP protection class : IP2x mounted in enclosure.Temperature :30°C according to EN61009-1 Pollution degree :2 according to EN61009-1 The combo-circuit breakers are all with one pole and neutral - in a two-module width (36mm).Technical specifications:Current rating(A) :10 Trip curve:B Number of poles:1P+N Fault tripping current(mA) :30
