Varunummer: 3238103
TRENDnet TPE-3524SF - switch - 52-port web - 52 ports - smart - rack-mountable - TAA Compliant
Switch, 52-port, web, L2+, smart, 48 x 10/100/1000 (PoE+) + 4 x 10 Gigabit SFP+, skrivbordsmodell, rackmonterbar, PoE+ (740 W), TAA-kompatibel
9 110,00 kr
7 288,00 kr exkl. moms
Gratis frakt
Beställningsvara - leveranstid kan ej upplysas
TRENDnet's 52-Port Gigabit Web Smart PoE+ Switch with 10G SFP+ ports, model TPE-3524SF, offers advanced L2+ features with enhanced traffic management controls to meet the evolving demands of SMB networks. This managed PoE+ switch with SFP+ ports comes with an intuitive web-based interface. Advanced managed switch features include LACP to group ports together to increase bandwidth between switches, VLANs for segmenting and isolating virtual LAN groups, QoS for traffic prioritization, port bandwidth controls, and SNMP monitoring, making this a powerful solution for SMB networks. Improve voice performance by isolating and prioritizing VoIP traffic from normal data traffic with the easy-to-use voice VLAN feature.Free up router resources by offloading routing processes to the managed switch by using the L2+ Managed IPv4/IPv6 static routing feature to efficiently route traffic at the switch level. The dynamic ARP inspection feature helps protect connected devices from man-in-the-middle attacks by discarding malicious and invalid ARP packets. Take advantage of the available multicast and IGMP/MLD snooping features to optimize IP surveillance system performance, and minimize network traffic. This TRENDnet Web Smart Managed PoE+ Switch also features 10G SFP+ ports to support long-distance fiber networking applications.Installers and integrators can save on equipment costs and reduce installation time with TRENDnet's Web Smart Managed PoE+ Switches by delivering up to 30W per port of PoE power and data over existing Ethernet cables. With PoE technology, users only need one set of cables to deliver both data and power. With this PoE+ managed switch, network PoE devices such as high-power wireless access points, PTZ and other advanced IP cameras, VoIP phone systems, IPTV decoders, access controls, and more.
Producent
Varunummer
3238103
Modell
TPE-3524SF
EAN
0710931162523
Till producentens hemsida
Switch typ
hanterad
Antal grundläggande RJ-45 Ethernet-portar
48
Typ av grundläggande RJ-45 Ethernet-portar
Gigabit Ethernet (10/100/1000)
Antal SFP+-modulplatser
4
Konsolport
RJ-45
Kommunikationsstandarder
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G stöd
Ja
Full duplex
Ja
Halv duplex
Ja
Länkaggregering
Ja
STP (Spanning Tree Protocol)
Ja
Head-of-line (HOL) blockering
Ja
VLAN-stöd
Ja
VLAN-funktioner
Private VLAN, Tagged VLAN, Voice VLAN
Antal VLAN
4094
Adresstabellstorlek
32000 poster
Switch kapacitet
176 Gbit/s
Hastighet vid vidarebefordran
130,95 Mpps
Jumbo Frames stöd
Ja
Jumboramar
9000
DHCP-funktioner
DHCP snooping
IGMP-snooping
Ja
Multicast-stöd
Ja
Lednings Protokoll
SNMP v1, v2c, v3
Antal fläktar
3 fläkt/-ar
Ljudnivå Lc IEC
42,7 dB
Medeltid mellan fel (MTBF)
70599 h
AC-inspänning
100 - 240 V
Växelström Frekvens
50/60 hz
Strömförbrukning (max)
52 W
Effekt skyddsfunktioner
Överspänning, Kortslutning
Strömförsörjning via Ethernet (PoE) stöd
Ja
Power over Ethernet (PoE)-effekt per port
30 W
Total Power over Ethernet (PoE)-budget
740 W
Temperatur vid drift
0 - 50 ° C
Bredd
440 mm
Djup
310 mm
Höjd
44 mm
Vikt
4,72 kg
Certifiering
CE
FCC
UL
Management features
Switch typ
hanterad
Anslutningar
Antal grundläggande RJ-45 Ethernet-portar
48
Typ av grundläggande RJ-45 Ethernet-portar
Gigabit Ethernet (10/100/1000)
Antal SFP+-modulplatser
4
Konsolport
RJ-45
Nätverk
Kommunikationsstandarder
IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G stöd
Ja
Full duplex
Ja
Halv duplex
Ja
Länkaggregering
Ja
STP (Spanning Tree Protocol)
Ja
Head-of-line (HOL) blockering
Ja
VLAN-stöd
Ja
VLAN-funktioner
Private VLAN, Tagged VLAN, Voice VLAN
Antal VLAN
4094
Data transmission
Adresstabellstorlek
32000 poster
Switch kapacitet
176 Gbit/s
Hastighet vid vidarebefordran
130,95 Mpps
Jumbo Frames stöd
Ja
Jumboramar
9000
Bevakning
DHCP-funktioner
DHCP snooping
IGMP-snooping
Ja
Multicast-funktioner
Multicast-stöd
Ja
Protokoll
Lednings Protokoll
SNMP v1, v2c, v3
Design
Antal fläktar
3 fläkt/-ar
Prestanda
Ljudnivå Lc IEC
42,7 dB
Medeltid mellan fel (MTBF)
70599 h
Strömtillförsel
AC-inspänning
100 - 240 V
Växelström Frekvens
50/60 hz
Strömförbrukning (max)
52 W
Effekt skyddsfunktioner
Överspänning, Kortslutning
Power over Ethernet (PoE)
Strömförsörjning via Ethernet (PoE) stöd
Ja
Power over Ethernet (PoE)-effekt per port
30 W
Total Power over Ethernet (PoE)-budget
740 W
Miljökrav
Temperatur vid drift
0 - 50 ° C
Vikt & dimension
Bredd
440 mm
Djup
310 mm
Höjd
44 mm
Vikt
4,72 kg
Certifikat
Certifiering
CE
FCC
UL
Ovanstående information och specifikationer är vägledande och kan utan förvarning ändras av producenten. Alla uppgifter lämnas med reservation för tryckfel, och bilder är vägledande. Vissa texter kan vara autogenererade eller maskinöversatta och kan därför ge texter som kan vara missvisande.
